Install NVCC For Jupyter#
Requirement already satisfied: nvcc4jupyter in /system/conda/miniconda3/envs/cloudspace/lib/python3.10/site-packages (1.2.1)
Note: you may need to restart the kernel to use updated packages.
Load the NVCC Extension#
Source files will be saved in "/tmp/tmp9pqtvywp".
Matrix Multipliation with 1D Grid & 1D Block#
%%cuda
#include <stdio.h>
#define N 8
__global__ void gemm(int* dA, int* dB, int* dC, int mat_dim)
{
int threadId = (blockIdx.x*blockDim.x) +threadIdx.x;
int sum= 0;
int row = threadId/mat_dim;
int col = threadId%mat_dim;
if (row < N && col < N)
{
for (int k=0 ; k<mat_dim; k++)
{
sum = sum + (dA[(row*mat_dim)+k] * dB[(k*mat_dim)+col]);
}
dC[threadId] = sum;
}
}
__host__ int main(){
printf("GEMM Started\n");
int* A;
int* B;
int* C;
int* dA;
int* dB;
int* dC;
A = (int*) malloc(N*N*sizeof(int));
B = (int*) malloc(N*N*sizeof(int));
C = (int*) malloc(N*N*sizeof(int));
cudaMalloc((void**)&dA, N*N * sizeof(int));
cudaMalloc((void**)&dB, N*N * sizeof(int));
cudaMalloc((void**)&dC, N*N * sizeof(int));
for (int i=0; i<N; i++)
{
for (int j=0; j<N; j++)
{
A[i*N+j] = i*N+j;
B[i*N+j] = i*N+j;
}
}
cudaMemcpy(dA, A, N*N*sizeof(int), cudaMemcpyHostToDevice);
cudaMemcpy(dB, B, N*N*sizeof(int), cudaMemcpyHostToDevice);
gemm<<<1,N*N>>>(dA,dB,dC,N);
cudaDeviceSynchronize();
cudaError_t err = cudaGetLastError();
if (err != cudaSuccess) {
printf("Kernel Launch Failed: %s\n", cudaGetErrorString(err));
}
printf("GEMM Completed Successfully\n");
cudaMemcpy(C,dC, N*N*sizeof(int), cudaMemcpyDeviceToHost);
for (int i=0; i<N; i++)
{
for (int j=0; j<N; j++)
{
printf("%u ",C[i*N+j]);
}
printf("\n");
}
cudaFree(dA);
cudaFree(dB);
cudaFree(dC);
free(A);
free(B);
free(C);
}
GEMM Started
GEMM Completed Successfully
1120 1148 1176 1204 1232 1260 1288 1316
2912 3004 3096 3188 3280 3372 3464 3556
4704 4860 5016 5172 5328 5484 5640 5796
6496 6716 6936 7156 7376 7596 7816 8036
8288 8572 8856 9140 9424 9708 9992 10276
10080 10428 10776 11124 11472 11820 12168 12516
11872 12284 12696 13108 13520 13932 14344 14756
13664 14140 14616 15092 15568 16044 16520 16996
Matrix Multiplications using using 2D Grid & 2D Block#
%%cuda
#include <stdio.h>
#define N 8
__global__ void gemm(int* dA, int* dB, int* dC, int matDim){
int row = blockIdx.y*blockDim.y + threadIdx.y;
int col = blockIdx.x*blockDim.x + threadIdx.x;
int sum =0;
if(row<N && col<N)
{
for (int k=0;k<N;k++){
sum = sum + dA[row*N+k] * dB[k*N+col];
}
dC[row*N+col] = sum;
}
}
__host__ int main(){
int *A, *B, *C;
int *dA, *dB, *dC;
A = (int*) malloc(N*N*sizeof(int));
B = (int*) malloc(N*N*sizeof(int));
C = (int*) malloc(N*N*sizeof(int));
cudaMalloc( (void**)&dA, N*N*sizeof(int));
cudaMalloc( (void**)&dB, N*N*sizeof(int));
cudaMalloc( (void**)&dC, N*N*sizeof(int));
for (int i=0; i<N; i++)
{
for (int j=0; j<N; j++ )
{
A[i*N+j] = i*N+j;
B[i*N+j] = i*N+j;
}
}
cudaMemcpy(dA, A, N*N*sizeof(int), cudaMemcpyHostToDevice);
cudaMemcpy(dB, B, N*N*sizeof(int), cudaMemcpyHostToDevice);
int block_size= 4;
dim3 blockDim(block_size,block_size);
dim3 gridDim((N+block_size-1)/block_size, (N+block_size-1)/block_size);
gemm<<<gridDim,blockDim>>>(dA,dB,dC,N);
cudaDeviceSynchronize();
cudaMemcpy(C,dC,N*N*sizeof(int), cudaMemcpyDeviceToHost);
for(int i=0; i<N; i++)
{
for(int j=0; j<N; j++)
{
printf("%u ", C[i*N+j]);
}
printf("\n");
}
cudaFree(dA);
cudaFree(dB);
cudaFree(dC);
free(A);
free(B);
free(C);
}
1120 1148 1176 1204 1232 1260 1288 1316
2912 3004 3096 3188 3280 3372 3464 3556
4704 4860 5016 5172 5328 5484 5640 5796
6496 6716 6936 7156 7376 7596 7816 8036
8288 8572 8856 9140 9424 9708 9992 10276
10080 10428 10776 11124 11472 11820 12168 12516
11872 12284 12696 13108 13520 13932 14344 14756
13664 14140 14616 15092 15568 16044 16520 16996
Matrix Multiplications using using 1D Grid & 3D Block#
%%cuda
#include <stdio.h>
#define N 8
#define BLOCK_SIZE 4
__global__ void gemm(int* dA, int* dB, int* dC, int matDim){
int localThreadId = threadIdx.z*blockDim.y*blockDim.x + threadIdx.y*blockDim.x+threadIdx.x;
int globalThreadId = (blockIdx.x * blockDim.x* blockDim.y * blockDim.z) + localThreadId;
int row = globalThreadId/matDim;
int col = globalThreadId%matDim;
int sum =0;
if(row<N && col<N)
{
for (int k=0;k<N;k++){
sum = sum + dA[row*N+k] * dB[k*N+col];
}
dC[row*N+col] = sum;
}
}
__host__ int main(){
int *A, *B, *C;
int *dA, *dB, *dC;
A = (int*) malloc(N*N*sizeof(int));
B = (int*) malloc(N*N*sizeof(int));
C = (int*) malloc(N*N*sizeof(int));
cudaMalloc( (void**)&dA, N*N*sizeof(int));
cudaMalloc( (void**)&dB, N*N*sizeof(int));
cudaMalloc( (void**)&dC, N*N*sizeof(int));
for (int i=0; i<N; i++)
{
for (int j=0; j<N; j++ )
{
A[i*N+j] = i*N+j;
B[i*N+j] = i*N+j;
}
}
cudaMemcpy(dA, A, N*N*sizeof(int), cudaMemcpyHostToDevice);
cudaMemcpy(dB, B, N*N*sizeof(int), cudaMemcpyHostToDevice);
dim3 blockDim(BLOCK_SIZE,BLOCK_SIZE,BLOCK_SIZE);
dim3 gridDim((N+BLOCK_SIZE-1)/BLOCK_SIZE);
gemm<<<gridDim,blockDim>>>(dA,dB,dC,N);
cudaDeviceSynchronize();
cudaMemcpy(C,dC,N*N*sizeof(int), cudaMemcpyDeviceToHost);
for(int i=0; i<N; i++)
{
for(int j=0; j<N; j++)
{
printf("%u ", C[i*N+j]);
}
printf("\n");
}
cudaFree(dA);
cudaFree(dB);
cudaFree(dC);
free(A);
free(B);
free(C);
}
1120 1148 1176 1204 1232 1260 1288 1316
2912 3004 3096 3188 3280 3372 3464 3556
4704 4860 5016 5172 5328 5484 5640 5796
6496 6716 6936 7156 7376 7596 7816 8036
8288 8572 8856 9140 9424 9708 9992 10276
10080 10428 10776 11124 11472 11820 12168 12516
11872 12284 12696 13108 13520 13932 14344 14756
13664 14140 14616 15092 15568 16044 16520 16996
